TP-Link VIGI C230I Mini 3MP IR Dome Network Camera – H.265+, Smart IR 30m, Human & Vehicle Detection, PoE
SKU: C230I
$89.00
$99.00
Free shipping
Estimated delivery: 3-5 business days
Description
The TP-Link VIGI C230I Mini is a compact 3MP IR Dome Network Camera designed for professional indoor surveillance in retail stores, offices, hotels, schools, and commercial environments. It delivers 2304 × 1296 (3MP) resolution, Smart IR night vision up to 30 m, H.265+ video compression, intelligent detection features, and supports PoE (802.3af) for simplified installation.
Key Features
3MP High-Definition Video
- 3 Megapixel CMOS Sensor
- Maximum Resolution: 2304 × 1296
- Sharp and detailed surveillance footage
- Suitable for continuous 24/7 monitoring
Smart IR Night Vision
- IR Distance: Up to 30 m (98 ft)
- Smart IR technology
- Automatic day/night switching
- Clear images in low-light environments
Intelligent Video Analytics
Supports:
- Human Detection
- Vehicle Detection
- Motion Detection
- Line Crossing Detection
- Intrusion Detection
- Region Entrance Detection
- Region Exiting Detection
- Camera Tampering Detection
Video Compression
Supports:
- H.265+
- H.265
- H.264+
- H.264
H.265+ reduces bandwidth and storage requirements while maintaining image quality.
Lens Options
Available with fixed lens options:
- 2.8 mm
- 4 mm
Provides wide-angle coverage depending on deployment requirements.
Image Features
- Wide Dynamic Range (Digital WDR)
- 3D Digital Noise Reduction (3D DNR)
- Backlight Compensation (BLC)
- Highlight Compensation (HLC)
- White Balance
- Image Enhancement
Audio
- Built-in Microphone (model-dependent/regional availability)
- Audio over IP
(Availability may vary by regional model.)
Network Features
- ONVIF Compatibility
- RTSP Support
- IPv4 / IPv6
- Web Management
- VIGI App
- VIGI Security Manager
- VIGI NVR Integration
Power Options
Supports:
- 802.3af PoE
- 12V DC
PoE enables power and data transmission over a single Ethernet cable.
Smart Management
Compatible with:
- VIGI Security Manager
- VIGI App
- Web Interface
- VIGI NVR
- Remote Monitoring
Technical Specifications
| Specification | Details |
|---|---|
| Model | VIGI C230I Mini |
| Camera Type | IR Dome Network Camera |
| Sensor | 3MP Progressive Scan CMOS |
| Resolution | 2304 × 1296 |
| Lens Options | 2.8 mm / 4 mm |
| Night Vision | Up to 30 m |
| Video Compression | H.265+, H.265, H.264+, H.264 |
| PoE | IEEE 802.3af |
| Power | 12V DC / PoE |
| Network | RJ45 10/100 Mbps |
| Protection | Indoor |
Intelligent Detection Features
- Human Detection
- Vehicle Detection
- Motion Detection
- Intrusion Detection
- Line Crossing
- Region Entrance
- Region Exit
- Camera Tampering Alarm
Image Enhancement Technologies
- Digital WDR
- 3D DNR
- BLC
- HLC
- Smart IR
- Day/Night Switching
Physical Specifications
| Specification | Details |
|---|---|
| Color | White |
| Form Factor | Mini Dome |
| Installation | Ceiling / Wall Mount |
| Housing | Indoor Dome Design |
Ideal For
- Offices
- Retail Stores
- Hotels
- Restaurants
- Schools
- Reception Areas
- Commercial Buildings
- Indoor Security Monitoring
Package Contents
- TP-Link VIGI C230I Mini Network Camera
- Mounting Accessories
- Quick Installation Guide
