The TP-Link SG3218XP-M2 is a high-performance L2+ Managed Multi-Gigabit PoE+ Switch designed for enterprise networks, SMBs, Wi-Fi 6/6E/7 deployments, surveillance systems, and high-speed office environments. It features 16 × 2.5 Gigabit PoE+ ports, 2 × 10 Gigabit SFP+ uplinks, centralized Omada SDN management, advanced Layer 2+ routing capabilities, and a 240 W PoE power budget.

Key Features

Multi-Gig Enterprise Switching

• 16 × 2.5GBASE-T RJ45 PoE+ Ports
• 2 × 10G SFP+ Fiber Uplink Ports
• Up to 140 Gbps Switching Capacity
• High-speed enterprise connectivity

240 W PoE+ Budget

Supports IEEE standards:

• IEEE 802.3af
• IEEE 802.3at

Features:

• Total PoE Budget: 240 W
• Up to 30 W per PoE+ port
• Intelligent PoE Management

Suitable for:

• Wi-Fi Access Points
• IP Cameras
• VoIP Phones
• Network Devices

Omada SDN Integration

Supports centralized cloud management via:

• Omada Hardware Controller
• Omada Software Controller
• Omada Cloud-Based Controller
• Omada App

Features include:

• Zero-Touch Provisioning*
• Centralized Monitoring
• Remote Management
• Bulk Configuration

*Zero-Touch Provisioning requires the Omada Cloud-Based Controller.

Layer 2+ Features

Supports:

• Static Routing
• VLAN
• 802.1Q VLAN
• Voice VLAN
• Private VLAN
• QinQ
• Link Aggregation (LACP)
• Spanning Tree (STP/RSTP/MSTP)
• Loop Prevention
• IGMP Snooping
• Multicast Management

Enterprise Security

Includes:

• ACL (Access Control Lists)
• 802.1X Authentication
• Port Security
• DHCP Snooping
• IP Source Guard
• ARP Inspection
• Storm Control
• Secure Web Management
• SSH
• SSL/TLS

QoS Features

Supports:

• L2/L3/L4 QoS
• DSCP
• 802.1p Priority
• Bandwidth Control
• Port Mirroring
• Traffic Scheduling

Ideal for:

• Voice
• Video Conferencing
• Streaming
• Business Applications

High-Speed Uplinks

Provides:

• 2 × 10G SFP+ Fiber Ports

Supports high-speed aggregation to:

• Core Switches
• NAS
• Servers
• Enterprise Backbone
• Data Centers

Hardware Specifications

Management

Supports:

• Omada SDN
• Web GUI
• CLI
• SNMP v1/v2c/v3
• RMON
• SSH
• Telnet
• Dual Image
• Dual Configuration

Network Features

• IPv4 Static Routing
• IPv6 Support
• Link Aggregation
• VLAN
• Voice VLAN
• ACL
• QoS
• DHCP Server/Relay
• IGMP Snooping
• MLD Snooping

Physical Specifications

Ideal Applications

• Enterprise Networks
• SMB Offices
• Wi-Fi 6 / Wi-Fi 6E / Wi-Fi 7 Deployments
• Hotels
• Schools
• Hospitals
• Surveillance Networks
• IP Telephony
• High-Speed Backbone Networks

Package Contents

• TP-Link SG3218XP-M2 Managed Switch
• Power Cord
• Rackmount Kit
• Rubber Feet
• Quick Installation Guide
