TP-Link Omada SG2005P-PD 5-Port Gigabit Smart Switch with 1-Port PoE++ In & 4-Port PoE+ Out – Managed, Fanless, Omada SDN
SKU: SG2005P
$145.00
$155.00
Free shipping
Estimated delivery: 3-5 business days
Description
The TP-Link Omada SG2005P-PD is a compact 5-Port Gigabit Smart Switch designed for flexible PoE deployments where AC power is unavailable or inconvenient. It is powered through a single PoE++ (802.3bt) uplink and redistributes power to connected PoE devices through four PoE+ (802.3af/at) output ports. With centralized Omada SDN management, Layer 2 smart switching features, VLAN support, QoS, and a fanless metal enclosure, it is ideal for IP surveillance, wireless access points, VoIP systems, and small business networks.
Key Features
PoE-Powered Smart Switch
- 1 × PoE++ (802.3bt) Powered Device (PD) Input
- 4 × PoE+ (802.3af/at) Power Sourcing Equipment (PSE) Output Ports
- Eliminates the need for a local AC power outlet
- Simplifies installations in ceilings, hallways, and remote locations
Gigabit Performance
- 5 × 10/100/1000 Mbps RJ45 Ports
- Non-blocking Gigabit switching
- Auto-Negotiation
- Auto MDI/MDIX
PoE Capability
- Powered by IEEE 802.3bt PoE++
- Supplies IEEE 802.3af/at PoE+ to downstream devices
- Intelligent PoE power allocation
- Suitable for powering wireless access points, IP cameras, and VoIP phones
Omada SDN Integration
Supports centralized management via:
- Omada Hardware Controller
- Omada Software Controller
- Omada Cloud-Based Controller
- Omada App
- Standalone Web Interface
Layer 2 Smart Features
Supports:
- 802.1Q VLAN
- Port-Based VLAN
- QoS
- IGMP Snooping
- Link Aggregation
- Port Mirroring
- Loop Prevention
- Storm Control
- Cable Diagnostics
Network Security
- Port Isolation
- ACL (Access Control Lists)
- 802.1X Authentication
- MAC Address Binding
- DoS Protection
- Secure Management
Silent Fanless Design
- Fanless operation
- Silent performance
- Metal enclosure
- Desktop or wall-mount installation
Suitable for offices, meeting rooms, classrooms, and retail environments.
Smart Management
Management options include:
- Omada SDN
- Cloud Management
- Web GUI
- CLI
- SNMP
- RMON
Technical Specifications
| Specification | Details |
|---|---|
| Model | SG2005P-PD |
| Product Type | Smart Managed Switch |
| Total Ports | 5 × Gigabit RJ45 |
| Uplink Power | 1 × PoE++ (802.3bt) PD |
| Downstream PoE | 4 × PoE+ (802.3af/at) |
| Switching Capacity | 10 Gbps |
| Packet Forwarding Rate | 7.44 Mpps |
| MAC Address Table | 8K |
| Management | Omada SDN / Web / CLI / SNMP |
| Installation | Desktop / Wall Mount |
| Cooling | Fanless |
Layer 2 Features
- 802.1Q VLAN
- Port VLAN
- QoS
- IGMP Snooping
- Link Aggregation
- Port Mirroring
- Loop Detection
- Storm Control
Security Features
- ACL
- 802.1X
- Port Isolation
- DoS Protection
- Secure Web Management
- MAC Filtering
Management Features
- Omada SDN
- Cloud Management
- Omada App
- Web Interface
- CLI
- SNMP
- RMON
Physical Specifications
| Specification | Details |
|---|---|
| Enclosure | Metal |
| Cooling | Fanless |
| Installation | Desktop / Wall Mount |
| Color | Black |
Ideal For
- Omada Wireless Access Points
- IP Cameras
- VoIP Phones
- Retail Stores
- Offices
- Schools
- Hotels
- Meeting Rooms
- Remote PoE Installations
- Small Business Networks
Package Contents
- TP-Link Omada SG2005P-PD Smart Switch
- Installation Guide
- Mounting Accessories
- Rubber Feet
