ASUS TUF Gaming GeForce RTX 5060 Ti 16GB GDDR7 OC Edition PCIe 5.0 DLSS 4 16GB Graphics Card
Description
The ASUS TUF Gaming GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition is a factory-overclocked NVIDIA Blackwell graphics card aimed at high-refresh 1080p and 1440p gaming, ray tracing, AI-enhanced rendering, and creator workloads. ASUS lists the exact model as TUF-RTX5060TI-O16G-GAMING.
Key Specifications
| Specification | Details |
|---|---|
| Model | TUF-RTX5060TI-O16G-GAMING |
| GPU | NVIDIA GeForce RTX™ 5060 Ti |
| Architecture | NVIDIA Blackwell |
| AI Performance | 759 TOPs |
| CUDA Cores | 4,608 |
| Video Memory | 16GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| PCI Express | PCIe 5.0 |
| OC Mode Clock | 2692 MHz |
| Default Boost Clock | 2662 MHz |
| OpenGL | 4.6 |
| Max Digital Resolution | 7680 × 4320 |
| HDMI | 1 × HDMI 2.1b |
| DisplayPort | 3 × DisplayPort 2.1b |
| HDCP | 2.3 |
| Maximum Displays | 4 |
| Power Connector | 1 × 16-pin |
| Recommended PSU | 550W |
| Slot Size | 3.1-slot |
| Dimensions | 302 × 133.5 × 62 mm |
| Aura Sync | Yes |
Main Performance Features
The card combines the RTX 5060 Ti GPU with 16GB of GDDR7 memory running at 28 Gbps on a 128-bit bus. The OC Edition raises the clock to 2692 MHz in OC mode, compared with a 2662 MHz default boost clock.
Key selling points for a listing:
- NVIDIA Blackwell Architecture
- 16GB GDDR7
- 4,608 CUDA Cores
- 28 Gbps Memory
- Factory Overclocked
- PCIe 5.0
- Up to 8K Output
- Four-display support
- Aura Sync RGB
NVIDIA Gaming & AI Technologies
This GPU generation supports NVIDIA's current RTX feature set, including:
- DLSS 4
- Multi Frame Generation
- 4th-generation Ray Tracing Cores
- 5th-generation Tensor Cores
- NVIDIA Reflex 2
- NVIDIA Studio
- AV1 encode/decode
- NVIDIA Broadcast
- DirectX 12 Ultimate
These make the card suitable for gaming as well as GPU-accelerated content creation and AI-assisted workflows.
ASUS TUF Cooling & Build
The TUF version uses ASUS's larger 3.1-slot cooling design and measures 302 × 133.5 × 62 mm, so buyers should verify chassis clearance before purchase. ASUS also lists Aura Sync support for lighting customization.
For your listing, the strongest cooling/build talking points are:
- TUF Gaming triple-fan cooling
- Large heatsink design
- Reinforced construction
- Protective backplate
- Aura Sync ARGB
- GPU Tweak III support
Display Connectivity
The card provides:
- 3 × DisplayPort 2.1b
- 1 × HDMI 2.1b
- Up to 4 simultaneous displays
- Maximum digital resolution of 7680 × 4320
- HDCP 2.3
Power Requirements
- Recommended PSU: 550W
- GPU power connector: 1 × 16-pin
- PCIe interface: PCI Express 5.0
ASUS notes that its PSU recommendation is based on a fully overclocked CPU/GPU system configuration.
Package Contents
ASUS officially lists:
- 1 × Speed Setup Manual
- 1 × TUF Graphics Card Holder
- 1 × TUF Velcro Hook & Loop
- 1 × TUF Gaming Certificate
- 1 × Thank You Card
- 1 × Adapter Cable (1-to-2)
