ASUS TUF Gaming GeForce RTX 5060 Ti 16GB GDDR7 OC Edition Graphics Card | NVIDIA Blackwell | DLSS 4 | PCIe 5.0 | Aura Sync
SKU: TUF Gaming GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition
$1,287.00
$1,299.00
Free shipping
Estimated delivery: 3-5 business days
Description
The ASUS TUF Gaming GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition is a factory-overclocked graphics card built on the NVIDIA Blackwell architecture. Designed for gamers and creators, it features 4,608 CUDA cores, 16GB of GDDR7 memory, a durable TUF Gaming 3.1-slot cooling solution, PCIe 5.0 support, and advanced AI capabilities powered by DLSS 4. The exact model is TUF-RTX5060TI-O16G-GAMING.
| Specification | Details |
|---|---|
| Model | TUF-RTX5060TI-O16G-GAMING |
| GPU | NVIDIA GeForce RTX™ 5060 Ti |
| Architecture | NVIDIA Blackwell |
| AI Performance | Up to 759 TOPS |
| CUDA Cores | 4,608 |
| Video Memory | 16GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| PCI Express | PCIe 5.0 |
| OC Mode Clock | 2692 MHz |
| Default Boost Clock | 2662 MHz |
| OpenGL | 4.6 |
| Maximum Resolution | 7680 × 4320 |
| Display Outputs | 3 × DisplayPort 2.1b |
| HDMI | 1 × HDMI 2.1b |
| HDCP | 2.3 |
| Maximum Displays | 4 |
| Power Connector | 1 × 8-pin PCIe |
| Recommended PSU | 550W |
| Slot Design | 3.1-slot |
| Dimensions | 302 × 133.5 × 62 mm |
| Lighting | ASUS Aura Sync ARGB |
Key Features
- NVIDIA Blackwell Architecture
- Factory Overclocked (2692 MHz OC Mode)
- 16GB GDDR7 High-Speed Memory
- 28 Gbps Memory Speed
- 128-bit Memory Interface
- DLSS 4 with Multi Frame Generation
- 4th Gen Ray Tracing Cores
- 5th Gen Tensor Cores
- NVIDIA Reflex 2
- PCI Express 5.0
- TUF Gaming Triple Axial-tech Fans
- MaxContact Heat Spreader
- Large Vapor Chamber
- Ventilated Aluminum Backplate
- Dual BIOS (Performance / Quiet)
- Military-Grade Components
- Auto-Extreme Manufacturing
- Aura Sync RGB Lighting
- Protective PCB Coating
- GPU Guard Technology
- Phase-Change GPU Thermal Pad
- SFF-Ready Enthusiast Compatible
Display Connectivity
- 3 × DisplayPort 2.1b
- 1 × HDMI 2.1b
- Supports up to 4 Displays
- Maximum Digital Resolution: 7680 × 4320 (8K)
Physical Specifications
| Item | Details |
|---|---|
| Card Length | 302 mm |
| Width | 133.5 mm |
| Thickness | 62 mm |
| Slot Occupancy | 3.1-slot |
| Power Connector | 1 × 8-pin PCIe |
| Recommended PSU | 550W |
Cooling Technologies
- Triple Axial-tech Fans
- MaxContact Technology
- Large Vapor Chamber
- Vented Aluminum Backplate
- Dual BIOS
- 0dB Silent Technology
- Phase-Change GPU Thermal Pad
Creator Features
- NVIDIA Studio
- NVIDIA Broadcast
- AV1 Hardware Encoding
- CUDA Acceleration
- AI Rendering
- Tensor AI Processing
Gaming Technologies
- NVIDIA DLSS 4
- Multi Frame Generation
- NVIDIA Reflex 2
- Ray Reconstruction
- DirectX 12 Ultimate
- NVIDIA G-SYNC
- Vulkan RT
- OpenGL 4.6
Package Contents
- ASUS TUF Gaming GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition
- Speed Setup Manual
- TUF Gaming Velcro Hook & Loop Strap
- TUF Gaming Certificate
- Thank You Card
Supported Software
- ASUS GPU Tweak III
- MuseTree
- NVIDIA App
- NVIDIA Game Ready Driver
- NVIDIA Studio Driver
