ASUS PRIME GeForce RTX 5060 Ti 8GB GDDR7 OC Edition Graphics Card | NVIDIA Blackwell | DLSS 4 | PCIe 5.0
Description
The ASUS PRIME GeForce RTX™ 5060 Ti 8GB GDDR7 OC Edition is a factory-overclocked graphics card built on NVIDIA Blackwell architecture. It combines 4,608 CUDA cores, 8GB of GDDR7 memory, PCIe 5.0, DLSS 4 support, and ASUS PRIME’s triple-fan 2.5-slot cooling design for high-refresh gaming and creator workloads. The exact model is PRIME-RTX5060TI-O8G.
| Specification | Details |
|---|---|
| Model | PRIME-RTX5060TI-O8G |
| GPU | NVIDIA GeForce RTX™ 5060 Ti |
| Architecture | NVIDIA Blackwell |
| AI Performance | 759 TOPS |
| CUDA Cores | 4,608 |
| Video Memory | 8GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| PCI Express | PCIe 5.0 |
| OC Mode Clock | 2647 MHz |
| Default Boost Clock | 2617 MHz |
| OpenGL | 4.6 |
| Maximum Resolution | 7680 × 4320 |
| DisplayPort | 3 × DisplayPort 2.1b |
| HDMI | 1 × HDMI 2.1b |
| HDCP | 2.3 |
| Maximum Displays | 4 |
| Power Connector | 1 × 8-pin |
| Recommended PSU | 550W |
| Slot Size | 2.5-slot |
| Dimensions | 304 × 120 × 50 mm |
ASUS lists the OC Edition at 2647 MHz in OC mode and 2617 MHz default boost, compared with 2602/2572 MHz on the standard PRIME RTX 5060 Ti 8GB version.
The card uses 8GB GDDR7 memory running at 28 Gbps over a 128-bit interface. It supports up to four displays through 3 × DisplayPort 2.1b and 1 × HDMI 2.1b, with a maximum digital resolution of 7680 × 4320 (8K).
For system integration, the card measures 304 × 120 × 50 mm, occupies 2.5 slots, uses a single 8-pin PCIe power connector, and ASUS recommends a 550W PSU.
