ASUS Dual GeForce RTX 5060 Ti 16GB GDDR7 OC Edition Graphics Card | NVIDIA Blackwell | DLSS 4 | PCIe 5.0
Description
The ASUS Dual GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition is the black dual-fan factory-overclocked version of ASUS’s RTX 5060 Ti 16GB card. It uses NVIDIA Blackwell architecture, 4,608 CUDA cores, 16GB GDDR7, PCIe 5.0, and a compact 2.5-slot Dual cooling design. The exact model is DUAL-RTX5060TI-O16G.
| Specification | Details |
|---|---|
| Model | DUAL-RTX5060TI-O16G |
| GPU | NVIDIA GeForce RTX™ 5060 Ti |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 4,608 |
| Video Memory | 16GB GDDR7 |
| Memory Speed | 28 Gbps |
| Memory Interface | 128-bit |
| PCI Express | PCIe 5.0 |
| OC Mode Clock | 2647 MHz |
| Default Boost Clock | 2617 MHz |
| OpenGL | 4.6 |
| Maximum Resolution | 7680 × 4320 |
| DisplayPort | 3 × DisplayPort 2.1b |
| HDMI | 1 × HDMI 2.1b |
| HDCP | 2.3 |
| Maximum Displays | 4 |
| Power Connector | 1 × 8-pin |
| Recommended PSU | 550W |
| Slot Design | 2.5-slot |
| Dimensions | 229 × 120 × 50 mm |
The card’s strongest selling points are 16GB GDDR7 at 28 Gbps, DLSS 4, Multi Frame Generation, 4th Gen Ray Tracing Cores, 5th Gen Tensor Cores, NVIDIA Reflex 2, and PCI Express 5.0.
For cooling, the ASUS Dual design uses two Axial-tech fans, dual-ball fan bearings, a large heatsink, 0dB silent operation, a protective backplate, Dual BIOS, and Auto-Extreme manufacturing. Its compact 229 × 120 × 50 mm size makes it suitable for more compact gaming builds than many triple-fan RTX 5060 Ti cards.
For display connectivity, it provides 3 × DisplayPort 2.1b + 1 × HDMI 2.1b, supports up to four displays, and can output up to 7680 × 4320 (8K).
Package contents typically include the ASUS Dual GeForce RTX™ 5060 Ti 16GB GDDR7 OC Edition graphics card, Speed Setup Manual, ASUS Hook & Loop strap, and Thank You Card.
