AOC AM400G Single Monitor Arm Gray | Mechanical Spring | 17–34" | 2–9kg | VESA 75x75 / 100x100 | Height Adjustable | C-Clamp & Grommet
Description
The AOC AM400G is a single-monitor desk arm in gray, built from aluminum alloy and designed for monitors from 17" to 34" weighing 2–9 kg. It uses a mechanical spring adjustment system for smooth positioning and supports VESA 75 × 75 mm and 100 × 100 mm mounting.
| Specification | Details |
|---|---|
| Brand | AOC |
| Model | AM400G |
| Product Type | Single Monitor Arm |
| Color | Gray |
| Material | Aluminum Alloy |
| Adjustment System | Mechanical Spring |
| Supported Screen Size | 17"–34" |
| Weight Capacity | 2–9 kg |
| VESA Compatibility | 75 × 75 mm / 100 × 100 mm |
| Maximum Height | 495 mm |
| Height Adjustment Range | 250 mm |
| Maximum Extension | Approx. 455 mm |
| Tilt Range | -15° to +90° |
| Swivel Range | -90° to +90° |
| Pivot / Rotation | 360° |
| Cable Management | Built-in |
| Desk Mounting | C-Clamp or Grommet |
| Net Weight | Approx. 2.4 kg |
| Gross Weight | Approx. 2.8–2.9 kg |
| Package Dimensions | 405 × 195 × 115 mm |
Mechanical Spring System
The arm uses a mechanical spring tensioning system that allows the monitor to move smoothly when extending, retracting, tilting, or rotating. The spring tension can be adjusted to suit lighter or heavier supported monitors.
Ergonomic Adjustment
The AM400G offers a wide range of movement:
- 250 mm height adjustment
- Up to 495 mm maximum height
- Approx. 455 mm extension
- -15° to +90° tilt
- -90° to +90° swivel
- 360° pivot
This allows landscape or portrait positioning and easier adjustment of viewing height and angle.
Monitor Compatibility
Supports:
- 17" to 34" monitors
- Monitor weight from 2 kg to 9 kg
- VESA 75 × 75 mm
- VESA 100 × 100 mm
Desk Mounting
Two installation methods are included:
- C-Clamp mount
- Grommet mount
AOC specifies compatible desktop thickness of roughly 15–50 mm for the clamp/grommet configurations depending on the installation method and regional documentation.
Built-In Cable Management
Integrated cable-management channels help route power and display cables along the arm, keeping the desk cleaner while allowing the display to move.
Construction
- Gray finish
- Aluminum-alloy arm
- Mechanical spring mechanism
- Compact desk-mounted design
- Removable VESA mounting plate
- Integrated cable routing
Package Contents
AOC lists:
- AOC AM400G Monitor Arm
- C-Clamp Mount
- Grommet Mount
- Installation Hardware
- User Manual
Main Product Highlights
- Single Monitor Arm
- 17"–34" Monitor Support
- 2–9 kg Load Capacity
- Mechanical Spring System
- 250 mm Height Adjustment
- Up to 495 mm Height
- Approx. 455 mm Extension
- -15° to +90° Tilt
- ±90° Swivel
- 360° Rotation
- VESA 75 × 75 / 100 × 100 mm
- C-Clamp + Grommet Installation
- Integrated Cable Management
- Aluminum Alloy Construction
- Gray Finish
